Phaser 8400/8500/8550/8560 Color Printer Service Manual 2-31
Theory of Operation
Transfix and Print Speeds
Transfix Speeds
Characteristic
Setpoint, Paper Media
Fast Color Standard Enhanced High Res/
Peak Transfix Speed,
Simplex tray feed
20 ips (8400)
25 ips (8500/
8550/8560)
17 ips (8400)
25 ips (8500/
8550/8560)
13 ips (8400)
20 ips (8500/
8550/8560)
7 ips (8400)
10 ips (8500/
8550/8560)
Peak Transfix Speed,
Duplex
5 ips (8400)
10 ips (8500/
8550/8560)
5 ips (8400
10 ips (8500/
8550/8560)
5 ips (8400
10 ips (8500/
8550/8560)
5 ips (8400)
10 ips (8500/
8550/8560)
Peak Transfix Speed,
Legal
20 ips 17 ips 13 ips 7 ips
Peak Transfix Speed,
Tray 1
13 ips 7 ips 7 ips 7 ips
First Sheet Transfix
Speed
7 ips 7 ips 7 ips 7 ips
Setpoint, OHP Media
Peak Transfix Speed 5 ips
Approximate Print Speeds (8400 Series)
Tray (Source) /
Resolution
Simplex, A4 Paper Auto Duplex, A4 Paper
Tray 1
Fast Color (300x300 dpi) 10 pages per minute
(ppm)
10 sides per minute (spm)
Standard (300x450 dpi) 9 ppm 9 spm
Enhanced (563x400 dpi) 8 ppm 4 spm
High Res/Photo (525 x
2400)
6 ppm 3 spm
PCL 600 x 300 Mode
PCL 600 x 600 Mode
6.5 ppm
3 ppm
Tray 2 - 4
Fast Color (300 x 300 dpi) 24 ppm 15 spm
Standard (300 x 450 dpi) 18 ppm 13 spm
Enhanced (563 x 400 dpi) 12 ppm 11 spm
High Res/Photo
(525x2400)
7 ppm 7 spm
PCL 600 x 300 Mode
PCL 600 x 600 Mode
13 ppm
6 ppm
