Phaser 8400/8500/8550/8560 Color Printer Service Manual 8-33
Service Parts Disassembly
Inner Simplex Guide (PL3.0.1)
1. Open the Front Door to access the guide.
2. Using a small flatblade screwdriver, pry inward on one retainer to remove
it from the mounting post then remove the other retainer.
3. Slide the guide down and forward to remove.
R
ep
l
acemen
t
N
o
t
e
The fingers on the Inner Simplex Guide, go over the segmented roller.
First snap the left retainer into place, then the right.
Lower Inner Duplex Guide (PL3.0.2)
1. Open the Front Door.
2. Pull out on the tabs at the bottom of the guide and let the guide swing
free.
3. Pry inward (toward the center of the printer) on the right upper retainer
until it is free of the mounting boss and remove the guide.
Lower Exit-Guide Assembly with Strip Flag (PL3.0.3)
1. Open the Exit Cover.
2. Lift upward on the center of the guide, then flex the left retainer inward to
remove it.
3. Remove the right retainer and remove the guide.
