Phaser 8400/8500/8550/8560 Color Printer Service Manual 9-5
Parts Lists
Parts List 1.0 Covers
No. Name/Description Qty Part Number
1 Front Door (MPT) Assembly 1 200467880 (8400)
848K06520 (8500/8550/8560)
2 Front Door Stay Retainer Clip 2 120E29140
3 Front Door Stay with Spring 2 009K02390
4 Hinge Pins, Front Door 2 029E49330
5 Control Panel Cover 1 200467380 (8400)
802E93850 (8500/8550/8560)
6 Control Panel with Bezel 1 657012880 (8400)
802K93650 (8500/8550/8560)
7 Exit Cover Assembly
Exit Cover with Badge
1 200469380 (8400)
802K93590 (8500)
802K88420 (8550)
848K12760 (8560)
8 Ink Loader Door (part of PL 2.1) 1 See PL2.0.1
9 Left Side Cover 1 200467680 (8400)
802K93660 (8500/8550/8560)
10 Right Side Cover Assembly with Doors 1 200467580 (8400)
802K93570 (8500/8550/8560)
11 Drum Maintenance Door (Side) 1 200469480 (8400)
802E93870 (8500/8550/8560)
12 I/O Access Door 1 200468480 (8400)
802E93860 (8500/8550/8560)
13 Waste Tray Cover 1 802E93880
14 Waste Tray 1 109R00736
