Xerox Phaser 8500 Service Manual

Phaser 8400/8500/8550/8560 Color Printer Service Manual 9-7
Parts Lists
Parts List 2.0 Imaging
No. Name/Description Qty Part Number
1 Ink Loader Assembly and Door 1 200469880 (8400)
133K27710 (8500/8550)
133K27770 (8560)
103K01600 (Metered 8550/8560)
2 Printhead 1 650430300 (8400)
046K00530 (8500/8550)
017K04540 (8560)
3 Drum Assembly, includes Encoder 1 105115080 (8400)
020K15090 (8500/8550/8560)
4 Belt, Y-Axis Drum 1 214498780 (8400)
023E30670 (8500/8550/8560)
5 Printhead Wiper 1 367053480 (8400/8500/8550)
033E05290 (8560)
6 Belt, Wiper Drive 1 214501280 (8400/8500/8550)
023E31250 (8560)
7 Purge Pressure Pump 1 094E02790
8 Left Printhead Restraint 1 120E29160
9 Right Printhead Restraint 1 120E29150
10 Transfix Camshaft Assembly 1 384187480 (8400)
008K02160 (8500/8550/8560)
11 Drum Maintenance Camshaft
Assembly
1 401100380 (8400)
020K14800 (8500/8550/8560)
12 Stripper Carriage Assembly 1 386735280 (8400)
041K06500 (8500/8550/8560)
13 Transfix Roller 1 022E32290
14 Y-Axis Tension Spring 1 809E69920
15 Transfix Load Module 1 386739380 (8400)
137E24130 (8500/8550/8560)
16 Drum Maintenance Pivot Plate
Assembly
1 020K15100
17 Preheater and Deskew Assembly 1 119641980 (8400)
126E02721 (8500/8550/8560)
18 Transfix Arm Assembly 1 401101280 (8400)
059K50011 (8500/8550/8560)
19 X-Axis Bias Spring Hook 1 019E75180
20 X-Axis Roll Adjuster Spring 1 809E69940
21
X-Axis Bias Spring
1 809E69930
