Phaser 8400/8500/8550/8560 Color Printer Service Manual 9-9
Parts Lists
Parts List 3.0 Paper Path
No. Name/Description Qty Part Number
1 Inner Simplex Guide 1 351111480 (8400)
032E29480 (8500/8550/8560)
2 Lower Inner Duplex Guide 1 038K16870
3 Lower Exit Guide Assembly with Strip
Flag
1 038K17800
4 Outer Duplex Paper Guide with Sensors
(Safety Interlocks)
1 032K04640
5 Upper Duplex Guide with Solenoid 1 351113280 (8400)
032K04630 (8500/8550/8560)
6 Exit Roller 1 059E05610
7 Take Away Roller 1 022E32420
8 Duplex Roller 1 022E32410
9 Separator Pad Kit 1 650429300 (8400)
604K31140 (8500/8550/8560)
10 Pick Assembly and Retard Roller Kit 1 650429200 (8400)
604K42200 (8500/8550/8560)
11 Main Tray (Tray 2) 1 650433200 (8400)
050E23080 (8500/8550/8560)
12 525-Sheet Feeder and Tray
525-Sheet Feeder and Tray
1 059K58610 (8400)
050E23570 (8500/8550/8560)
13 Exit Module Assembly 1 441223980 (8400)
133K27700 (8500/8550/8560)
To Next Page
