Phaser 8400/8500/8550/8560 Color Printer Service Manual 9-13
Parts Lists
Parts List 5.0 Circuit Boards and Cables
No. Name/Description Qty Part Number
1 Cable, Y-Axis Motor Ground 1 117E34880
2 Wiring Harness, Left Side Power
Control
1 174449480 (8400)
117E29800 (8500/8550/8560)
3 Cable, Wave Amp Signal 1 174446580 (8400)
117E34870 (8500/8550/8560)
4 Wave Amp 1 671522380 (8400)
960K21181 (8500/8550/8560)
5 Electronics Module (no RAM,
NVRAM, or Configuration Card)
1 119649580 (8400)
137E14020 (8500/8550)
137E24440 (8560)
6 Cable, Printhead Interface 1 117E29840
7 Hard Drive
Hard Drive with Japanese Fonts
1 097S03172 (8400)
121K44411 (8500/8550)
121K45340 (8560)
097S03173 (8400)
121K44420 (8500/8550)
8 128 MB SDRAM
256 MB SDRAM
128 MB SDRAM
256 MB SDRAM
512 MB SDRAM
1 156483700 (8400)
156466300 (8400)
237E23890 (8500/8550/8560)
237E23640 (8500/8550/8560)
237E23650 (8550/8560)
9 8-pin NVRAM 1 856476800
10 Configuration Card-B
Configuration Card-BD
Configuration Card-N
Configuration Card-DP
Configuration Card-DX
Configuration Card-DN
Configuration Card-DP, DT and DX
Configuration Card-DN, DT and DX
1 650431200 (8400)
650431300 (8400)
650431400 (8400)
069E00360 (8500)
069E00550 (8560)
650431500 (8400)
650431600 (8400)
069E00370 (8500)
069E00380 (8550)
069E00560 (8560)
11 Cable, Flex, Wave Amp Drive 1 174448680 (8400)
117E29790 (8500/8550/8560)
12 Cable, Right Side Power Control 1 117E29820
13 I/O Board 1 671529100 (8400)
960K22331 (8550/8550)
14 Cable, Combined Right (Ink Loader
Data, Preheater AC)
1 174451180 (8400)
117E29810 (8500/8550/8560)
15 Cable, I/O Board Data 1 117E29830
16 Cable, Right Umbilical 1 117E28790
17 Drum Heater Relay Board 1 960K35170
18 Cable, Front Door 1 117E28780
19 Cable, Control Panel 1 117E35230 (8500/8550/8560)
