Xerox Phaser 8500 Service Manual

Phaser 8400/8500/8550/8560 Color Printer Service Manual 2-15
Theory of Operation
W
arn
i
ng
When servicing the printer be careful of the purge system as it passes the
Printhead. If a damaged Wiper Blade catches on the Printhead, it could
propel hot liquid ink upward into your face.
s8500-018
Purge Pump
Solenoid Valve
Purge Tube
Printhead
Printhead
Drum
Wiper
30 Sec
(Open During Wiper Action)
