06/2014

3-10

WC 5022/5024

3.1.4 Image Quality Troubleshooting

Version 1.0

Image Quality Troubleshooting

IQ11 Repeating Bands,Streaks,Spots,and Smears RAP

Black lines or blank areas running along the paper in h.orizontal direction.

Procedure

Check the operating parts of the IIT Carriage for foreign substances and distortion. No distor-

tion or foreign substances are found in the operating parts of the carriage.

Remove the foreign substances. If the Pulley, Shaft, IIT Carriage Belt (PL 1.3) (REP

1.3.2), etc. is deformed, replace it.

Remove the Drum Cartridge (PL 8.1) (REP 8.1.1) and reinstall it. Turn the power OFF then ON

and print. The problem reoccurs.

End

Install the new Drum Cartridge (PL 8.1) (REP 8.1.1) securely. Turn the power OFF then ON

and print. The problem reoccurs.

End

Check the surface of the BTR for contamination and distortion. The surface of the BTR is

clean and there is no distortion.

Clean the BTR. If there is distortion, replace the BTR Roll (PL 6.1) (REP 4.1.1).

Check the pitch of the black lines or blank areas. The pitch of the black lines is approx. 78

mm (Heat Roll circumference).

Clean the Heat Roll. If there is difficulty in removing the contamination, replace the Fusing

Unit (PL 7.1) (REP 7.1.1).

Replace the ROS Assembly (PL 2.1) (REP 2.1.1), followed by the ESS/MCU PWB (PL 18.3)

(REP 18.3.2).

IQ12 Mottle RAP

A phenomenon where an uneven density is occurring in the high density patch image.

Procedure

Check the paper type. Paper used is within specifications.

Use paper within specifications.

Use paper from a freshly opened packet. The problem reoccurs.

End

Remove the Drum Cartridge (PL 8.1) (REP 8.1.1) and reinstall it. Turn the power OFF then ON

and print. The problem reoccurs.

End

Install the new Drum Cartridge (PL 8.1) (REP 8.1.1) securely. Turn the power OFF then ON

and print. The problem reoccurs.

End

Check the surface of the BTR for contamination and distortion. The surface of the BTR is

clean and there is no distortion.

Clean the BTR. If there is distortion, replace the BTR Roll (PL 6.1) (REP 4.1.1).

Remove the HVPS and reinstall it. Turn the power OFF then ON and print. The problem

reoccurs.

End

Replace the ESS/MCU PWB (PL 18.3) (REP 18.3.2).
