06/2014

3-12

WC 5022/5024

3.1.4 Image Quality Troubleshooting

Version 1.0

Image Quality Troubleshooting

IQ15 Blank Image RAP

Paper is printed completely white.

Procedure

Check the installation of the ROS Assembly. The ROS Unit is installed correctly.

Install the ROS Assembly (PL 2.1) (REP 2.1.1) correctly.

Check the drum ground contact point for contamination and distortion. The drum ground

contact point is clean and there is no distortion.

Clean the drum ground contact point. Correct the distortion.

Remove the Drum Cartridge (PL 8.1) (REP 8.1.1) and reinstall it. Turn the power OFF then ON

and print. The problem reoccurs.

End

Install the new Drum Cartridge (PL 8.1) (REP 8.1.1) securely. Turn the power OFF then ON

and print. The problem reoccurs.

End

Print a page that is entirely black. During the print cycle, turn OFF the power after the feeding

sound is heard. (i.e. forcing to stop the transfer in mid-progress). Check the surface of the

Drum. There is a considerable amount of toner left on the surface of the drum.

Check the connection of the P/J140, P/J410, P/J160, and P/J411 connectors. The

connectors are connected correctly.

Connect the connector cable securely.

Check the installation of the ROS Assembly (PL 2.1) (REP 2.1.1). The ROS Assembly

is installed securely.

Install the ROS Assembly (PL 2.1) (REP 2.1.1) securely.

Measure the voltage between the ESS/MCU PWB (PL 18.3) (REP 18.3.2) P410 pin-1

and pin-2. The voltage is +5VDC.

Replace the ESS/MCU PWB (PL 18.3) (REP 18.3.2).

Check the connection between J140 and J410 for open circuit and short circuit. The

connection between J140 and J410 is conducting normally with no open circuit

and no short circuit.

Repair the open circuit or short circuit.

Replace the ROS Assembly (PL 2.1) (REP 2.1.1), followed by the ESS/MCU PWB (PL

18.3) (REP 18.3.2).

Replace the BTR Roll (PL 6.1) (REP 4.1.1), followed by the HVPS (PL 18.3) (REP 18.1.2) and

the ESS/MCU PWB (PL 18.3) (REP 18.3.2)).
