3.5 Cycle Table
Image Quality Troubleshooting
Version 1.0
3.5 Cycle Table
*1: This is 50.24/1.86=27 mm because the rotation is at 1.86 times the peripheral speed.
Table 1
Item Module Name Diameter (mm) Pitch (mm)
1 PH Regi Roll 20 63
2 DEVE Mag Roll 16 27*1
13.5 (half-pitch)
3 XERO BCR 12 38
4 DRUM(OPC) 30 94
5 BTR 16 50
6 Fusing Unit Heat Roll 25 79
7 Pressure Roll 30 94
8 Exit Roll 15 47
