Xerox WorkCentre 5024 Service Manual

06/2014
5-65
WC 5022/5024
Common Hardware, Part Number Index
Parts List
Version 1.0
Common Hardware
Item Part Description
AA 112W27898 Pan Head Screw (M3x8)
AB 113W20478 Screw (M3x4:White)
AC 113W20678 Screw (M3x6:White)
AD 113W20698 Round Screw (M3x6)
AE 113W20878 Screw (M3x8:White)
AF 113W21098 Round Screw (M3x10)
AG 113W21678 Screw (M3x16:White)
AH 113W27488 Pan Head Screw (M3x4:White)
AJ 113W27688 Pan Head Screw (M3x6:White)
AK 114W27678 Bind Head Tapping Screw
(M3x6:White) (P 0.5)
AL 115W27878 Bind Head Tapping Screw
(3x8:White) (P 1.4)
AM 115W28078 Bind Head Tapping Screw
(3x10:White) (P 1.4)
AN 116W27678 Bind Head Screw (M3x6:White)
AP 153W16088 Tapping Screw (M4x10:White)
AQ 153W16288 Tapping Screw (M4x12:White)
AR 153W17688 Tapping Screw (M3x6:White)
AS 153W17888 Tapping Screw (M3x8:White)
AT 153W18088 Tapping Screw (M3x10:White)
AU 153W27678 Bind Head Tapping Screw
(M3x6:White) (P 1.06)
AV 153W27878 Bind Head Tapping Screw
(M3x8:White) (P 1.06)
AW 158W27678 Screw (M3x6:White)
AX 158W27688 Round Point Screw (M3x7:White)
AY 158W27878 Screw (M3x8:White)
AZ 252W29450 Nylon Washer (8) (t 1)
BA 271W11250 Dowel Pin (1.6x12)
BB 271W16050 Dowel Pin (2x10)
BC 271W21050 Dowel Pin (2.5x10)
BD 354W15278 E-Clip (2:White)
BE 354W19278 E-Clip (2.5:White)
BF 354W21254 KL-Clip (3)
BG 354W21278 E-Clip (3:White)
BH 354W24254 KL-Clip (4)
BJ 354W24278 E-Clip (4:White)
BK 354W26278 E-Clip (5:White)
BL 354W27254 KL-Clip (6)
BM 354W27278 E-Clip (6:White)
BN 354W29278 E-Clip (8:White)
BP 158W36678 Screw (M4x16:White)
BQ 158W45078 Screw (M5x10:White)
BR 113W20588 Pan Head Screw (M2.5x5)
Part Number Index
Table 1 Part Number Index
Part Number Part List
003E59630 PL 10.4
003E59630 PL 11.4
003E59640 PL 11.4
003E59640 PL 10.4
003E60941 PL 9.3
003E60952 PL 9.1
003E61510 PL 10.1
003E61510 PL 11.1
004K03410 PL 56.1
005K05890 PL 11.3
005K05890 PL 10.3
005K06760 PL 10.3
005K06760 PL 11.3
005K07010 PL 10.3
005K07010 PL 11.3
005E25160 PL 8.3
005E33441 PL 1.4
005E33441 PL 1.9
005K81880 PL 10.3
005K83081 PL 11.3
005K83081 PL 10.3
005K83510 PL 13.3
005K83520 PL 13.3
005K83551 PL 9.1
005K83930 PL 3.2
006R01573 PL 8.1
006E78490 PL 10.6
006E78490 PL 11.6
006E79021 PL 9.3
006K89940 PL 9.1
007K18170 PL 11.6
007K18660 PL 13.3
007K18750 PL 8.2
007K19210 PL 10.6
007E78220 PL 11.6
007E78230 PL 11.6
007E78240 PL 11.6
007E78250 PL 11.6
007E78260 PL 11.6

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
