2. Symbology
Wiring Data
Version 1.0
Figure 21 9039
This symbol represents a document or paper and shows the direction in
which it runs.
Figure 22 9040
This symbol represents a heat, light or air signal and shows the direction
in which it runs.
Figure 23 9063
This symbol shows Control Logic.
Figure 24 9064
This symbol shows a double plug connector.
Figure 25 9065
This symbol shows a drawer plug connector.
Figure 26 9066
This symbol shows a shorting plug connector.
Figure 27 9028
This symbol shows the fasten is used for connection.
Table 1
Symbol Description
Figure 28 9067
This symbol shows that an electrically conductive material such as a
leaf spring and a plate is used for connection.
Figure 29 4001
This symbol shows the part the arrow points to has been modified by 1V.
Figure 30 4002
This symbol shows the part the arrow points to has not been modified by
1V. It still has the previous configuration.
Figure 31 5005
This symbol shows the whole figure or the framed illustration is modified
by 1V.
Figure 32 5006
This symbol shows the whole figure or the framed illustration has not
been modified by 1V. The area still has the previous configuration.
Figure 33 9074
This symbol shows derection the air flows.
Figure 34 9075
This symbol shows switch and is also used as Interlock Switch.
Table 1
Symbol Description
