2-6
Electronic control system
24 Engine ECM
Determines the engine operating conditions according to the in-
put signals from the sensors and switches which are installed at
various locations on the engine, and sends output signals to op-
erate the actuators to perform the various control functions.
25
Cam position sensor (PORT
EX)
Determines the stroke of each cylinder according to the signals
from both the pulser coil and the cam position sensor (PORT
EX).
Part name Function
