YASKAWA P1000

Setting 0: WC (Inch of Water)
Setting 1: PSI (Pounds per Square Inch)
Setting 2: GPM (Gallons per Minute)
Setting 3: F (Degrees Fahrenheit)
Setting 4: CFM (Cubic Feet per Minute)
Setting 5: CMH (Cubic Meters per Hour)
Setting 6: LPH (Liters per Hour)
Setting 7: LPS (Liters per Second)
Setting 8: Bar (Bar)
Setting 9: Pa (Pascal)
Setting 10: C (Degrees Celsius)
Setting 11: Mtr (Meters)
Setting 12: Ft (Feet)
Setting 13: LPM (Liters per Minute)
Setting 14: CMM (Cubic Meters per Minute)
Setting 15: Hg (Inches of Mercury)
Setting 25: None
n
b5-42: PI Output Monitor Calculation Method
No. Name Setting Range Default
b5-42 PI Output Monitor Calculation Method 0 to 3 0
Setting 0: Linear
The monitor displays PID output.
Setting 1: Square Root
The monitor displays square root PID output.
Setting 2: Quadratic
The monitor displays 1/(PID output)
2
Setting 3: Cubic
The monitor displays 1/(PID output)
3
Note: Used for U5-14 and U5-15 only.
n
b5-43/b5-44: PI Output 2 Monitor Max Upper/Lower 4 Digits
Set the maximum monitor value at maximum frequency. U5-14 and U5-15 show Custom PI output. U5-14 shows the upper
4 digits and U5-15 shows the lower 4 digits.
No. Name Setting Range Default
b5-43 PI Output 2 Monitor Max Upper 4 Digits 0 to 9999 0
b5-44 PI Output 2 Monitor Max Lower 4 Digits 0.00 to 99.99 0.00
Note: Used for U5-14 and U5-15 only.
n
b5-45: PI Output 2 Monitor Minimum
U5-14 and U5-15 show Custom PI Output. b5-45 sets the minimum display value at zero speed. This function is effective
when b5-42 is set to 0 (Linear).
Note: Used for U5-14 and U5-15 only.
No. Name Setting Range Default
b5-45 PI Output 2 Monitor Minimum 0.0 to 999.9 0.0
Note: Used for U5-14 and U5-15 only.
