Setting 1: -10 to 10 V
u
F6 and F7: Communication Option Card
These parameters configure communication option cards and communication fault detection methods.
Some parameters apply to all communication option cards and some parameters apply to certain network options only. The
option cards are applicable to the parameter rows marked with an “O”.
Comm.
Protocol
Parameter Range
F6-01 to
F6-03
F6-04
F6-06 to
F6-08
F6-10 to
F6-14
F6-20,
F6-21
F6-22
F6-23 to
F6-26
F6-30 to
F6-32
F6-35,
F6-36
F6-45 to
F6-49
F6-50 to
F6-63
F7-01 to
F7-15
F7-16
F7-17 to
F7-42
CC-Link O O O O – – – – – – – – – –
MECHA-
TROLINK-II
O – O – O O O – – – – – – –
MECHA-
TROLINK-
III
O – O – O – O – – – – – – –
PROFIBUS-
DP
O – O – – – – O – – – – – –
CANopen O – O – – – – – O – – – – –
EtherCAT O – O – – – – – – – – – – –
BACnet O – – – – – – – – O – – – –
DeviceNet O – O – – – – – – – O – – –
LonWorks O – O – – – – – – – – – – –
Modbus
TCP/IP
O – O – – – – – – – – O O –
PROFINET O – O – – – – – – – – O – O
EtherNet/IP O – O – – – – – – – – O – O
n
F6-01: Communications Error Operation Selection
Determines drive operation when a communication error occurs.
No. Parameter Name Setting Range Default
F6-01 Communications Error Operation Selection 0 to 5 1
Setting 0: Ramp to Stop (Use the Deceleration Time Set to C1-02)
Setting 1: Coast to Stop
Setting 2: Fast Stop (Use the Fast Stop Time Set to C1-09)
Setting 3: Alarm Only (Continue Operation)
Setting 4: Alarm Only (Continue Operation Using the Frequency Reference Set in d1-04)
Setting 5: Alarm and Ramp to Stop
Note: Settings 4 and 5 available in drive software versions PRG: 8503 and later.
n
F6-02: External Fault from Comm. Option Detection Selection
Determines the detection method of an external fault initiated by a communication option (EF0).
No. Parameter Name Setting Range Default
F6-02 External Fault from Comm. Option Detection Selection 0, 1 0
Setting 0: Always Detected
Setting 1: Detection during Run Only
5.6 F: Option Settings
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
199
5
Parameter Details

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
