Page #285 background image
No. Name Setting Range Default
S6-02 Emergency Override Reference Selection 0, 1 0
Setting 0: Use S6-01 Reference
Setting 1: Use Frequency Reference
n
S6-07: Output Phase Loss Detection Level for Dynamic Audible Noise Control
Sets the output phase loss detection level for Dynamic Audible Noise Control. Decrease the setting in steps of 10% when
output phase loss is detected erroneously. This setting rarely needs to be changed.
No. Name Setting Range Default
S6-07
Output Phase Loss Detection Level for Dynamic Audible Noise
Control
10.0 to 100.0% 100.0%
u
T: Motor Tuning
Auto-Tuning automatically sets and tunes parameters required for optimal motor performance.
Refer to Auto-Tuning on page 129 for details on Auto-Tuning parameters.
5.11 S: Special Application
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
285
5
Parameter Details
