YASKAWA P1000

5.7 H: Terminal Functions
H parameters assign functions to the external terminals.
u
H1: Multi-Function Digital Inputs
n
H1-01 to H1-08: Functions for Terminals S1 to S8
These parameters assign functions to the multi-function digital inputs. The various functions and settings are listed in Table
5.29.
No. Parameter Name
Setting
Range
Default
H1-01 Multi-Function Digital Input Terminal S1 Function Selection 1 to 9F
40 (F)
<1>
: Forward Run Command (2-Wire sequence)
H1-02 Multi-Function Digital Input Terminal S2 Function Selection 1 to 9F
41 (F)
<1>
: Reverse Run Command (2-Wire sequence)
H1-03 Multi-Function Digital Input Terminal S3 Function Selection 0 to 9F 24: External Fault
H1-04 Multi-Function Digital Input Terminal S4 Function Selection 0 to 9F 14: Fault Reset
H1-05 Multi-Function Digital Input Terminal S5 Function Selection 0 to 9F
3 (0)
<1>
: Multi-Step Speed Reference 1
H1-06 Multi-Function Digital Input Terminal S6 Function Selection 0 to 9F
4 (3)
<1>
: Multi-Step Speed Reference 2
H1-07 Multi-Function Digital Input Terminal S7 Function Selection 0 to 9F
6 (4)
<1>
: Jog Reference Selection
H1-08 Multi-Function Digital Input Terminal S8 Function Selection 0 to 9F
8: (6)
<1>
: External Baseblock Command
<1> Number appearing in parenthesis is the default value after performing a 3-Wire initialization (A1-03 = 3330).
Table 5.29 Multi-Function Digital Input Terminal Settings
Setting Function Page
0 3-Wire Sequence 206
1 LOCAL/REMOTE Selection 206
2 External Reference 1/2 Selection 207
3 Multi-Step Speed Reference 1
2074 Multi-Step Speed Reference 2
5 Multi-Step Speed Reference 3
6 Jog reference Selection 207
7 Accel/Decel Time Selection 1 207
8 Baseblock Command (N.O.)
207
9 Baseblock Command (N.C.)
A Accel/Decel Ramp Hold 207
B Drive Overheat Alarm (oH2) 208
C Analog Terminal Input Selection 208
F Through Mode 208
10 Up Command
208
11 Down Command
12 Forward Jog
209
13 Reverse Jog
14 Fault Reset 209
15 Fast Stop (N.O.) 209
17 Fast Stop (N.C.) 209
18 Timer Function Input 210
19 PID Disable 210
1A Accel/Decel Time Selection 2 210
1B Program Lockout 210
1E Reference Sample Hold 210
20 to 2F External Fault 211
30 PID Integral Reset 211
31 PID Integral Hold 211
Setting Function Page
32 Multi-Step Speed Reference 4 211
34 PID Soft Starter Cancel 211
35 PID Input Level Selection 211
40 Forward Run Command (2-Wire sequence)
212
41 Reverse Run Command (2-Wire sequence)
42 Run Command (2-Wire sequence 2)
212
43 FWD/REV Command (2-Wire sequence 2)
47 Node Setup 212
51 Disable Sequence Timers 212
52 Cancel Active Sequence Timer 212
60 DC Injection Braking Command 212
61 External Speed Search Command 1 212
62 External Speed Search Command 2 212
63 Field Weakening 213
65 KEB Ride-Thru 1 (N.C.)
213
66 KEB Ride-Thru 1 (N.O.)
67 Communications Test Mode 213
68 High Slip Braking (HSB) 213
6A Drive Enabled 213
75 Up 2 Command
213
76 Down 2 Command
7A KEB Ride-Thru 2 (N.C.)
214
7B KEB Ride-Thru 2 (N.O.)
A8 Secondary PI Disable (N.O.) 214
A9 Secondary PI Disable (N.C.) 214
AA Secondary PI Inverse Operation 214
AB Secondary PI Integral Reset 214
AC Secondary PI Integral Hold 214
AD Select Secondary PI Parameters 215
5.7 H: Terminal Functions
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
205
5
Parameter Details
