1.4 Drive Models and Enclosure Types
Two types of enclosures are offered for P1000 drives:
• IP20/NEMA Type 1 enclosure models mount to an indoor wall or in an enclosure panel.
• IP00/Open Type enclosure models are designed for installation in an enclosure panel that serves to protect personnel from
injury caused by accidentally touching live parts.
Table 1.3 describes drive enclosures and models.
Table 1.3 Drive Models and Enclosure Types
Voltage Class
Enclosure Type
IP20/NEMA Type 1 Enclosure
<1>
Drive Model
IP00/Open Type Enclosure
Drive Model
Three-Phase
200 V Class
2A0004F
<1>
2A0006F
<1>
2A0008F
<1>
2A0010F
<1>
2A0012F
<1>
2A0018F
<1>
2A0021F
<1>
2A0030F
<1>
2A0040F
<1>
2A0056F
<1>
2A0069F
<1>
2A0081F
<1>
2A0110F
<1>
2A0138F
<1>
2A0169F
<1>
2A0211F
<1>
<2>
2A0250A
<2>
2A0312A
<2>
2A0360A
<3>
2A0415A
Three-Phase
400 V Class
4A0002F
<1>
4A0004F
<1>
4A0005F
<1>
4A0007F
<1>
4A0009F
<1>
4A0011F
<1>
4A0018F
<1>
4A0023F
<1>
4A0031F
<1>
4A0038F
<1>
4A0044F
<1>
4A0058F
<1>
4A0072F
<1>
1.4 Drive Models and Enclosure Types
34
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
