YASKAWA P1000 Technical Manual

u
S6: P1000 Protection
No.
(Addr.
Hex)
Name Description Values Page
S6-01
(3236)
Emergency Override Speed Sets the speed command used in emergency override mode when S6-02 = 0.
Default: 0.00 Hz
Min.: 0.00
Max.: 240.00
284
S6-02
(3237)
Emergency Override
Reference Selection
Selects the emergency override speed source.
0: Use S6-01 Reference
1: Use Frequency Reference
Default: 0
Range: 0, 1
284
S6-07
(323C)
Output Phase Loss Level for
Dynamic Noise Control
Reduces the output phase loss level when Dynamic Noise Control is active.
Default: 100.0%
Min.: 10.0
Max.: 100.0
285
u
S7: Output Current Limit
No.
(Addr.
Hex)
Name Description Values Page
S7-01
(324B)
<1>
Output Current Limit Select
Sets the function to enable and disable the output current regulator.
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
–
S7-02
(324C)
<1>
Current Limit
Sets the current limit. The value is internally limited to 300% of drive rated
current.
Default: 0.0 A
Min.: 0.0
Max.: 1000.0
–
S7-10
(3250)
<1>
Single Phase Foldback
Selection
Sets the function to enable and disable the single-phase ripple regulator.
0: Disabled
1: Enabled
Default: 1
Range: 0, 1
–
S7-11
(3251)
<1>
Ripple Regulator Setpoint
Set as a percentage of the maximum amount of ripple allowed before the drive
will detect and input phase loss fault.
Default: 95.0%
Min.: 0.0
Max.: 200.0
–
<1> Available in drive software versions PRG: 8503 and later.
B.12 S: Special Application
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
477
B
Parameter List

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
