Alarm and Error Displays
n
Faults
Table 6.4 gives an overview of possible fault codes. Conditions such as overvoltages can trip faults and alarms. It is important
to distinguish between faults and alarms to determine the proper corrective actions.
When the drive detects a fault, the ALM indicator LED lights, the fault code appears on the digital operator, and the fault
contact MA-MB-MC triggers. An alarm is present if the ALM LED blinks and the fault code on the digital operator flashes.
Refer to Minor Faults and Alarms on page 293 for a list of alarm codes.
Table 6.4 Fault Displays
Digital
Operator
Display
Name Page
bAT Digital Operator Battery Voltage Low 295
boL Braking Transistor Overload Fault 295
bUS Option Communication Error 295
CE MEMOBUS/Modbus Communication Error 295
CPF11 to
CPF14
<1> <3>
Control Circuit Error 296
CPF16 to
CPF19
<1> <3>
Control Circuit Error 296
CPF02 A/D Conversion Error 296
CPF03 Control Board Connection Error 296
CPF06
<3>
EEPROM Memory Data Error 296
CPF07,
CPF08
Terminal Board Connection Error 296
CPF20,
CPF21
<2>
Control Circuit Error 296
CPF22 Hybrid IC Error 297
CPF23 Control Board Connection Error 297
CPF24
<3>
Drive Unit Signal Fault 297
CPF25 Terminal Board Not Connected 297
CPF26 to
CPF35,
CPF40 to
CPF43
<4>
Control Circuit Error 297
E5 SI-T3 Watchdog Timer Error 297
EF0 Option Card External Fault 297
EF1 to EF8
External Fault
(input terminal S1 to S8)
297
Err EEPROM Write Error 298
FAn Internal Fan Fault 297
FbH Excessive PID Feedback 299
FbL PID Feedback Loss 299
GF Ground Fault 299
LF Output Phase Loss 299
LF2 Current Imbalance 300
LF3
<4>
Power Unit Output Phase Loss 3 300
nSE Node Setup Error 300
oC Overcurrent 300
Digital
Operator
Display
Name Page
oFA00
<3>
Option Card Connection Error
(CN5-A)
301
oFA01 Option Card Fault (CN5-A) 301
oFA03 to
oFA06
Option Card Error
(CN5-A)
301
oFA10,
oFA11
Option Card Error
(CN5-A)
301
oFA12 to
oFA17
Option Card Connection Error
(CN5-A)
301
oFA30 to
oFA43
Comm Option Card Connection Error
(CN5-A)
301
oFb00
<3>
Option Card Connection Error
(CN5-B)
301
oFb01 Option Card Fault (CN5-B) 302
oFb02 Option Card Fault (CN5-B) 302
oFb03,
oFb11
Option Card Error (CN5-B) 302
oFb12 to
oFb17
Option Card Connection Error
(CN5-B)
302
oFC00
<3>
Option Card Connection Error
(CN5-C)
302
oFC01 Option Card Fault (CN5-C) 302
oFC02 Option Card Fault (CN5-C) 302
oFC03,
oFC11
Option Card Error (CN5-C) 302
oFC12 to
oFC17
Option Card Connection Error
(CN5-C)
302
oFC50 to
oFC55
Option Card Error (CN5-C) 303
oH Heatsink Overheat 303
oH1 Heatsink Overheat 303
oH3 Motor Overheat Alarm (PTC input) 315
oH4 Motor Overheat Fault (PTC input) 303
oH5
<4>
Motor Overheat (NTC Input) 303
oL1 Motor Overload 303
oL2 Drive Overload 304
oL3 Overtorque Detection 1 304
oL4 Overtorque Detection 2 305
oL7 High Slip Braking oL 305
oPr Operator Connection Fault 305
ov Overvoltage 305
PF Input Phase Loss 306
rF Braking Resistor Fault 306
