YASKAWA P1000 Technical Manual

Register No. Contents
000FH
Control Selection Setting
bit 0 Reserved
bit 1 PID Setpoint Input
bit 2, 3 Reserved
bit 4 PI2 Target Input
bit 5 to B Reserved
bit C Enable Terminal S5 Input for Broadcast Data
bit D Enable Terminal S6 Input for Broadcast Data
bit E Enable Terminal S7 Input for Broadcast Data
bit F Enable Terminal S8 Input for Broadcast Data
0010H to 001AH Reserved
001BH Analog Monitor Option AO-A3 Analog Output 1 (10 V/4000 H)
001CH Analog Monitor Option AO-A3 Analog Output 2 (10 V/4000 H)
001DH to 001FH Reserved
3004H Set Time – Hours/Minutes (HHmm)
3005H Set Date – Year/Day of Week (YYdd)
3006H Set Date – Month/Day (MMDD)
3007H
RTC Set Command/Status
0 = Complete
1 = Set RTC data using registers 3004H to 3006H
8 = failed
302FH
RTC Enter
0 = Overwrite RTC data using registers 3004H to 3006H. Only effective when 3030H bit 1 (RTC Enter Enable) is set.
3030H
bit 1 RTC Enter Enable
bit 2 RTC TIE Fault Enable
u
Monitor Data
Monitor data can be read only.
Register No. Contents
0020H
Drive Status 1
bit 0 During Run
bit 1 During Reverse
bit 2 Drive Ready
bit 3 Fault
bit 4 Data Setting Error
bit 5 Multi-Function Contact Output (terminal M1-M2)
bit 6
bit 7
bit 8 to bit D Reserved
bit E ComRef status
bit F ComCtrl status
C.9 MEMOBUS/Modbus Data Table
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
521
C
MEMOBUS/Modbus Communications

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
