1.2 General Description
u
P1000 Model Selection
Refer to Table 1.1 for drive selection depending on motor power.
Note: The models and capacities in shown here are based on standard settings and operation conditions. Higher carrier frequencies and higher
ambient temperatures require derating.
Table 1.1 P1000 Models
Motor Power
HP
Three-Phase 200 V Class
Three-Phase 400 V Class Three-Phase 600 V Class
Drive Model
Rated Output
Current (A)
<3>
Drive Model
Rated Output
Current (A)
<3>
Drive Model
Rated Output
Current (A)
<3>
0.75 2A0004 3.5 4A0002 2.1 – –
1 2A0006 6 – – –
2 2A0008 8 4A0004 4.1 5A0003 2.7
3
2A0010 9.6 4A0005 5.4 5A0004 3.9
2A0012 12 4A0007 6.9 – –
5 2A0018 17.5 4A0009 8.8 5A0006 6.1
7.5 2A0021 21 4A0011 11.1 5A0009 9
10 2A0030 30 4A0018 17.5 5A0011 11
15 2A0040 40 4A0023 23 5A0017 17
20 2A0056 56 4A0031 31 5A0022 22
25 2A0069 69 4A0038 38 5A0027 27
30 2A0081 81 4A0044 44 5A0032 32
40 2A0110 110 4A0058 58 5A0041 41
50 2A0138 138 4A0072 72 5A0052 52
60 2A0169 169 4A0088 88 5A0062 62
75 2A0211 211 4A0103 103 5A0077 77
100 2A0250 250 4A0139 139 5A0099 99
125 2A0312 312 4A0165 165 5A0125 125
150 2A0360 360 4A0208 208 5A0145 145
175 2A0415 415 – – – –
200 – – 4A0250 250 5A0192 192
250 – – 4A0296 296 5A0242 242
300 – – 4A0362 362 – –
350 – – 4A0414 414 – –
400-450 – – 4A0515 515 – –
500-550 – – 4A0675 675 – –
750 – – 4A0930 930 – –
1000 – – 4A1200 1200 – –
<1> These values assume the carrier frequency is not set higher than 8 kHz.
<2> These values assume the carrier frequency is not set higher than 5 kHz.
<3> These values assume the carrier frequency is set to 2 kHz.
Note: Current derating is required when setting the carrier frequency higher. Refer to Drive Derating Data on page 407 for details.
1.2 General Description
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
