8.2 Drive Options and Peripheral Devices
Table 8.1 lists the names of the various peripheral devices, accessories, and options available for Yaskawa drives. Contact
Yaskawa or your Yaskawa agent to order these peripheral devices.
• Peripheral Device Selection: Refer to the Yaskawa catalog for selection and part numbers.
• Peripheral Device Installation: Refer to the corresponding option manual for installation instructions.
Table 8.1 Available Peripheral Devices
Option Model Number Description
Power Options
DC link choke – Improves the power factor by suppressing harmonic distortion from the power supply.
AC Reactor –
Protects the drive when operating from a large power supply and improves the power factor by
suppressing harmonic distortion. Highly recommended for power supplies that exceed 600 kVA.
Braking Resistor –
For use with systems that require dynamic braking with up to 3% ED. If higher ED is required,
use a Braking Resistor Unit.
Note: Not rated for 600 V class drive models.
Input/Output Option Cards
Analog Monitor AO-A3
• Provides extra multi-function analog output terminals
• Output channels: 2
• Output voltage: -10 to 10 V, 11-bit (signed)
Communication Option Cards
EtherNet/IP SI-EN3 Connects to an EtherNet/IP network.
Modbus TCP/IP SI-EM3 Connects to a Modbus TCP/IP network.
PROFINET
<1>
SI-EP3 Connects to a PROFINET network.
DeviceNet SI-N3 Connects to a DeviceNet network
PROFIBUS-DP SI-P3 Connects to a PROFIBUS-DP network.
MECHATROLINK-II SI-T3 Connects to a MECHATROLINK-II network.
BACnet SI-B3 Connects to a BACnet network.
CC-Link
<2>
SI-C3 Connects to a CC-Link network
CANopen
<2>
SI-S3 Connects to a CANopen network.
Interface Options
Remote Operator Cable
UWR000051, 1 m cable
UWR000052, 2 m cable
RJ-45, 8-pin straight through, UTP CAT5e, extension cable (1 m or 2 m) to connect the digital
operator for remote operation.
USB Copy Unit JVOP-181
• Allows the user to copy and verify parameter settings between drives.
• Functions as an adapter to connect the drive to a USB port on a PC.
Mechanical Options
Attachment for External
Heatsink
EZZ020800A/B/C/D
Installation kit for mounting the drive with the heatsink outside of the panel (Side-by-Side
mounting possible)
IP20/NEMA Type 1 Kit
100-054-503
100-054-504
Parts to make the drive conform to IP20/NEMA Type 1 enclosure requirements.
IP20/NEMA Type 1, 4, 12
Blank Keypad Kit
UUX0000526
Provides digital operator (JVOP-180, JVOP-182) functionality on an enclosure designed for
IP20/NEMA Type 1, 3R, 4, 4X, 12, or IPo6 environment. This keypad has a blank label on the
front.
IP20/NEMA Type 1, 4, 12
Yaskawa Logo Keypad Kit
UUX0000527
Provides digital operator (JVOP-180, JVOP-182) functionality on an enclosure designed for
IP20/NEMA Type 1, 3R, 4, 4X, 12, or IPo6 environment. This keypad has a Yaskawa brand
label on the front.
Others
24 V Power Supply
200 V Class: PS-A10LB
400 V Class: PS-A10HB
600 V Class: PS-A10HB
Supplies the drive controller with 24 Vdc power during main power loss.
PC Software Tools
DriveWizard Industrial Contact Yaskawa PC tool for drive setup and parameter management
<1> Available in drive software versions PRG: 8503 and later.
<2> Limited support. Contact a Yaskawa representative or the nearest Yaskawa sales office for assistance.
