B.16 Defaults by Drive Model
The following tables show parameters and default settings that change with the drive model selection (o2-04).
Table B.6 200 V Class Drives Default Settings by Drive Model Selection and ND settings
No. Name Unit Default Settings
Model CIMR-Po
2A0004 2A0006 2A0008 2A0010
o2-04 Drive Model Selection Hex. 62 63 64 65
E2-11 Motor Rated Output kW (HP)
0.75
(0.75)
1.1
(1)
1.5
(2)
2.2
(3)
b3-04 V/f Gain during Speed Search % 100 100 100 100
b3-06 Output Current 1 during Speed Search 1 0.5 0.5 0.5
b3-07
Output Current 2 during Speed Search
(Speed Estimation Type)
b3-26 Start Speed Search Select
b8-03 Energy Saving Control Filter Time Constant s 0.50 0.50 0.50 0.50
b8-04 Energy Saving Coefficient Value 223.7 196.6 169.4 156.8
C5-17 Motor Inertia
kgm
2
0.0028 0.0068 0.0068 0.0088
C6-02 Carrier Frequency Selection 7 7 7 7
E2-01 Motor Rated Current A 3.3 4.9 6.2 8.5
E2-02 Motor Rated Slip Hz 2.5 2.6 2.6 2.9
E2-03 Motor No-Load Current A 1.8 2.3 2.8 3
E2-05 Motor Line-to-Line Resistance Ω 5.156 3.577 1.997 1.601
E2-06 Motor Leakage Inductance % 13.8 18.5 18.5 18.4
E2-10 Motor Iron Loss for Torque Compensation W 26 38 53 77
L2-02 Momentary Power Loss Ride-Thru Time s 0.1 0.2 0.3 0.3
L2-03 Momentary Power Loss Minimum Baseblock Time s 0.3 0.4 0.4 0.5
L2-04 Momentary Power Loss Voltage Recovery Time s 0.3 0.3 0.3 0.3
L3-24 Motor Acceleration Time for Inertia Calculations s 0.142 0.142 0.166 0.145
L8-02 Overheat Alarm Level °C 115 115 115 115
L8-35 Installation Method Selection 2 2 2 2
L8-38 Carrier Frequency Reduction Selection 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10
B.16 Defaults by Drive Model
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
487
B
Parameter List
