YASKAWA P1000 Technical Manual

No. Name Unit Default Settings
–
Model CIMR-Po
– 2A0012 2A0018 2A0021 2A0030
o2-04 Drive Model Selection Hex. 66 67 68 6A
E2-11 Motor Rated Output kW (HP)
3.0
(3)
3.7
(5)
5.5
(7.5)
7.5
(10)
b3-04 V/f Gain during Speed Search % 100 100 100 100
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5
b3-07
Output Current 2 during Speed Search
(Speed Estimation Type)
– – – – –
b3-26 Start Speed Search Select – – – – –
b8-03 Energy Saving Control Filter Time Constant s 0.50 0.50 0.50 0.50
b8-04 Energy Saving Coefficient Value – 136.4 122.9 94.75 72.69
C5-17 Motor Inertia
kgm
2
0.0158 0.0158 0.0255 0.037
C6-02 Carrier Frequency Selection – 7 7 7 7
E2-01 Motor Rated Current A 11.4 14 19.6 26.6
E2-02 Motor Rated Slip Hz 2.7 2.73 1.5 1.3
E2-03 Motor No-Load Current A 3.7 4.5 5.1 8
E2-05 Motor Line-to-Line Resistance Ω 1.034 0.771 0.399 0.288
E2-06 Motor Leakage Inductance % 19 19.6 18.2 15.5
E2-10 Motor Iron Loss for Torque Compensation W 91 112 172 262
L2-02 Momentary Power Loss Ride-Thru Time s 0.5 1 1 1
L2-03 Momentary Power Loss Minimum Baseblock Time s 0.5 0.6 0.7 0.8
L2-04 Momentary Power Loss Voltage Recovery Time s 0.3 0.3 0.3 0.3
L3-24 Motor Acceleration Time for Inertia Calculations s 0.145 0.154 0.168 0.175
L8-02 Overheat Alarm Level °C 125 110 110 120
L8-35 Installation Method Selection – 2 2 2 2
L8-38 Carrier Frequency Reduction Selection – 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10
B.16 Defaults by Drive Model
488
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
