YASKAWA P1000 Technical Manual

No. Name Unit Default Settings
–
Model CIMR-Po
– 2A0040 2A0056 2A0069 2A0081
o2-04 Drive Model Selection Hex. 6B 6D 6E 6F
E2-11 Motor Rated Power
kW
(HP)
11
(15)
15
(20)
18.5
(25)
22
(30)
b3-04 V/f Gain during Speed Search % 100 100 100 100
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5
b3-07
Output Current 2 during Speed Search
(Speed Estimation Type)
– – – – –
b3-26 Start Speed Search Select – – – – –
b8-03 Energy Saving Control Filter Time Constant s 0.50 0.50 0.50 0.50
b8-04 Energy Saving Coefficient Value – 70.44 63.13 57.87 51.79
C5-17 Motor Inertia
kgm
2
0.053 0.076 0.138 0.165
C6-02 Carrier Frequency Selection – 7 7 7 7
E2-01 Motor Rated Current A 39.7 53 65.8 77.2
E2-02 Motor Rated Slip Hz 1.7 1.6 1.67 1.7
E2-03 Motor No-Load Current A 11.2 15.2 15.7 18.5
E2-05 Motor Line-to-Line Resistance Ω 0.23 0.138 0.101 0.079
E2-06 Motor Leakage Inductance % 19.5 17.2 15.7 19.5
E2-10 Motor Iron Loss for Torque Compensation W 245 272 505 538
L2-02 Momentary Power Loss Ride-Thru Time s 1 2 2 2
L2-03 Momentary Power Loss Minimum Baseblock Time s 0.9 1 1 1
L2-04 Momentary Power Loss Voltage Recovery Time s 0.3 0.6 0.6 0.6
L3-24 Motor Acceleration Time for Inertia Calculations s 0.265 0.244 0.317 0.355
L8-02 Overheat Alarm Level °C 125 120 120 125
L8-35 Installation Method Selection – 2 2 2 2
L8-38 Carrier Frequency Reduction Selection – 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10
B.16 Defaults by Drive Model
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
489
B
Parameter List

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
