B.1 Understanding Parameter Descriptions
u
Parameter Icons
The table below lists icons used in this section.
Table B.1 Icons Used in Parameter Descriptions
Symbol Description
Parameter can be changed during run.
u
Parameter Groups
Table B.2 P1000 Parameter Groups
Parameter
Group
Name Page
A1 Initialization Parameters 433
A2 User Parameters 433
b1 Operation Mode Selection 434
b2 DC Injection Braking and Short Circuit Braking 434
b3 Speed Search 435
b4 Timer Function 436
b5 PID Control 436
b6 Dwell Function 439
b8 Energy Saving 440
C1 Acceleration and Deceleration Times 441
C2 S-Curve Characteristics 441
C3 Slip Compensation 442
C4 Torque Compensation 442
C6 Carrier Frequency 442
d1 Frequency Reference 443
d3 Jump Frequency 444
d6 Field Weakening and Field Forcing 445
E1 V/f Pattern 446
E2 Motor 1 Parameters 447
F4 Analog Monitor Card (AO-A3) 448
F6, F7 Communication Option Card 448
H1 Multi-Function Digital Inputs 454
H2 Multi-Function Digital Outputs 457
H3 Multi-Function Analog Inputs 458
H4 Multi-Function Analog Outputs 460
H5 MEMOBUS/Modbus Serial Communication 461
Parameter
Group
Name Page
H6 Pulse Train Input/Output 461
L1 Motor Protection 463
L2 Momentary Power Loss Ride-Thru 463
L3 Stall Prevention 464
L4 Speed Detection 465
L5 Fault Restart 466
L6 Torque Detection 466
L8 Drive Protection 467
n1 Hunting Prevention 469
n3
High Slip Braking (HSB) and Overexcitation
Braking
469
o1 Digital Operator Display Selection 470
o2 Digital Operator Keypad Functions 471
o3 Copy Function 471
o4 Maintenance Monitor Settings 472
S1 Dynamic Noise Control Function 473
S2 Programmable Run Timers 473
S3 Secondary PI (PI2) Control 475
S6 P1000 Protection 477
S7 Output Current Limit 477
T1 Induction Motor Auto-Tuning 478
U2 Fault Trace 481
U3 Fault History 482
U4 Maintenance Monitors 483
U5 PID Monitors 485
U6 Operation Status Monitors 485
