E.3 User Setting Table
Use the Verify Menu to determine which parameters have been changed from their original default settings
below the parameter number indicates that the parameter setting can be changed during run.
No. Name
User
Setting
A1-00
Language Selection
A1-01
Access Level Selection
A1-03 Initialize Parameters
A1-04 Password
A1-05 Password Setting
A1-06 Application Preset
A2-01 to
A2-32
User Parameters, 1 to 32
A2-33 User Parameter Automatic Selection
b1-01 Frequency Reference Selection 1
b1-02 Run Command Selection 1
b1-03 Stopping Method Selection
b1-04 Reverse Operation Selection
b1-07 LOCAL/REMOTE Run Selection
b1-08
Run Command Selection while in Programming
Mode
b1-11 Run Delay Time Setting
b1-14 Phase Order Selection
b1-15 Frequency Reference Selection 2
b1-16 Run Command Selection 2
b1-17 Run Command at Power Up
b2-01 DC Injection Braking Start Frequency
b2-02 DC Injection Braking Current
b2-03 DC Injection Braking Time at Start
b2-04 DC Injection Braking Time at Stop
b3-01 Speed Search Selection at Start
b3-02 Speed Search Deactivation Current
b3-03 Speed Search Deceleration Time
b3-04 V/f Gain during Speed Search
b3-05 Speed Search Delay Time
b3-06 Output Current 1 during Speed Search
b3-07
Output Current 2 during Speed Search (Speed
Estimation Type)
b3-08
Current Control Gain during Speed Search (Speed
Estimation Type)
b3-10 Speed Search Detection Compensation Gain
b3-12
Minimum Current Detection Level during Speed
Search
b3-14 Bi-Directional Speed Search Selection
b3-17 Speed Search Restart Current Level
b3-18 Speed Search Restart Detection Time
b3-19 Number of Speed Search Restarts
b3-24 Speed Search Method Selection
b3-25 Speed Search Wait Time
No. Name
User
Setting
b3-26 Direction Determining Level
b3-27 Start Speed Search Select
b4-01 Timer Function On-Delay Time
b4-02 Timer Function Off-Delay Time
b5-01 PID Function Setting
b5-02
Proportional Gain Setting (P)
b5-03
Integral Time Setting (I)
b5-04
Integral Limit Setting
b5-05
Derivative Time (D)
b5-06
PID Output Limit
b5-07
PID Offset Adjustment
b5-08
PID Primary Delay Time Constant
b5-09 PID Output Level Selection
b5-10
PID Output Gain Setting
b5-11 PID Output Reverse Selection
b5-12 PID Feedback Loss Detection Selection
b5-13 PID Feedback Loss Detection Level
b5-14 PID Feedback Loss Detection Time
b5-15 PID Sleep Function Start Level
b5-16 PID Sleep Delay Time
b5-17 PID Accel/Decel Time
b5-18 PID Setpoint Selection
b5-19
<1>
PID Setpoint Value
b5-20 PID Setpoint Scaling
b5-34
PID Output Lower Limit
b5-35
PID Input Limit
b5-36 PID Feedback High Detection Level
b5-37 PID Feedback High Detection Time
b5-38 PID Setpoint User Display
b5-39 PID Setpoint Display Digits
b5-40 Frequency Reference Monitor Content during PID
b5-41 PI Output 2 Unit Selection
b5-42
PI Output 2 Calculation Mode
