YASKAWA P1000 Technical Manual

No. Name
User
Setting
b5-43
PI Output 2 Monitor Max Upper 4 Digits
b5-44
PI Output 2 Monitor Max Lower 4 Digits
b5-45
PI Output 2 Monitor Minimum
b5-46 PID Units Selection
b5-47 Reverse Operation Selection 2 by PID Output
b5-89
Sleep Method Selection
b5-90 EZ Sleep Unit
b5-91
EZ Minimum Speed
b5-92
EZ Sleep Level
b5-93
EZ Sleep Time
b5-94
EZ Wake-up Level
b5-95 EZ Wake-up Mode
b5-96
EZ Wake-up Time
b6-01 Dwell Reference at Start
b6-02 Dwell Time at Start
b6-03 Dwell Reference at Stop
b6-04 Dwell Time at Stop
b8-01 Energy Saving Control Selection
b8-04 Energy Saving Coefficient Value
b8-05 Power Detection Filter Time
b8-06 Search Operation Voltage Limit
C1-01
Acceleration Time 1
C1-02
Deceleration Time 1
C1-03
Acceleration Time 2
C1-04
Deceleration Time 2
C1-09
Fast-Stop Time
C1-10 Accel/Decel Time Setting Units
C1-11 Accel/Decel Time Switching Frequency
C2-01 S-Curve Characteristic at Accel Start
C2-02 S-Curve Characteristic at Accel End
C2-03 S-Curve Characteristic at Decel Start
C2-04 S-Curve Characteristic at Decel End
C3-01
Slip Compensation Gain
C3-02
Slip Compensation Primary Delay Time
No. Name
User
Setting
C3-03 Slip Compensation Limit
C3-04 Slip Compensation Selection during Regeneration
C4-01
Torque Compensation Gain
C4-02
Torque Compensation Primary Delay Time
C6-02 Carrier Frequency Selection
C6-03 Carrier Frequency Upper Limit
C6-04 Carrier Frequency Lower Limit
C6-05 Carrier Frequency Proportional Gain
d1-01
Frequency Reference 1
d1-02
Frequency Reference 2
d1-03
Frequency Reference 3
d1-04
Frequency Reference 4
d1-05
Frequency Reference 5
d1-06
Frequency Reference 6
d1-07
Frequency Reference 7
d1-08
Frequency Reference 8
d1-09
Frequency Reference 9
d1-10
Frequency Reference 10
d1-11
Frequency Reference 11
d1-12
Frequency Reference 12
d1-13
Frequency Reference 13
d1-14
Frequency Reference 14
d1-15
Frequency Reference 15
d1-16
Frequency Reference 16
d1-17
Jog Frequency Reference
d2-01 Frequency Reference Upper Limit
d2-02 Frequency Reference Lower Limit
d2-03 Master Speed Reference Lower Limit
d3-01 Jump Frequency 1
d3-02 Jump Frequency 2
d3-03 Jump Frequency 3
E.3 User Setting Table
574
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
