E.2 Basic Parameter Settings
Use the following tables to keep records of important parameters. Have this data available when contacting Yaskawa technical
support.
u
Basic Setup
Item Setting Value Memo
Frequency Reference Source b1-01 =
Run Command Source b1-02 =
u
V/f Pattern Setup
Item Setting Value Memo
V/f Pattern Selection E1-03 =
Max. Output Frequency E1-04 =
Max. Voltage E1-05 =
Base Frequency E1-06 =
Mid. Output Frequency E1-07 =
Mid. Output Frequency Volt. E1-08 =
Min. Output Frequency E1-09 =
Min. Output Frequency Volt. E1-10 =
u
Motor Setup
Motor Type Item Setting Value Memo
Induction
Motor Rated Current E2-01 =
Motor Rated Slip E2-02 =
Motor No-Load Current E2-03 =
No. of Motor Poles E2-04 =
Line-to-Line Resistance E2-05 =
Motor Leakage
Inductance
E2-06 =
u
Multi-Function Digital Inputs
Terminal Input Used
Setting Value
and Function Name
Memo
S1 H1-01 =
S2 H1-02 =
S3 H1-03 =
S4 H1-04 =
S5 H1-05 =
S6 H1-06 =
S7 H1-07 =
S8 H1-08 =
E.2 Basic Parameter Settings
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
571
E
Quick Reference Sheet

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
