7.4 Drive Cooling Fans
NOTICE: Follow cooling fan replacement instructions. The cooling fan cannot operate properly when installed incorrectly and could seriously
damage the drive. To ensure maximum useful product life, replace all cooling fans when performing maintenance.
Contact a Yaskawa representative or the nearest Yaskawa sales office to order replacement cooling fans as required.
For drives with multiple cooling fans, replace all the fans when performing maintenance to ensure maximum product
performance life.
u
Number of Cooling Fans
Drive Model Cooling Fans Circulation Fans Control Board Cooling Fans Page
Three-Phase 200 V Class
2A0004 – – – –
2A0006 – – – –
2A0008 – – – –
2A0010 – – – –
2A0012 – – – –
2A0018 1 – –
349
2A0021 1 – –
2A0030 2 – –
2A0040 2 – –
2A0056 2 – –
2A0069 2 – –
2A0081 2 – –
2A0110 2 – –
351
2A0138 2 – –
2A0169 2 – –
355
2A0211 2 – –
2A0250 2 – –
2A0312 2 – –
2A0360 3 1 –
2A0415 3 1 –
Three-Phase 400 V Class
4A0002 – – – –
4A0004 – – – –
4A0005 – – – –
4A0007 1 – –
349
4A0009 1 – –
4A0011 1 – –
4A0018 2 – –
4A0023 2 – –
4A0031 2 – –
4A0038 2 – –
4A0044 2 – –
4A0058 2 – –
351
4A0072 2 – –
4A0088 2 – –
353
4A0103 2 – –
7.4 Drive Cooling Fans
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
345
7
Periodic Inspection & Maintenance

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
