E2: Motor 1 Parameters
No.
(Addr.
Hex)
Name Description Values Page
E2-01
(30E)
Motor Rated Current
Sets the motor nameplate full load current in amps. Automatically set during
Auto-Tuning.
Default:
<1>
Min.: 10% of drive
rated current
Max.: 200% of
drive rated current
<2>
195
E2-02
(30F)
Motor Rated Slip
Sets the motor rated slip. Automatically set during Auto-Tuning.
Default:
<1>
Min.: 0.00 Hz
Max.: 20.00 Hz
195
E2-03
(310)
Motor No-Load Current
Sets the no-load current for the motor. Automatically set during Auto-Tuning.
Default:
<1>
Min.: 0 A
Max.: E2-01
<2>
196
E2-04
(311)
Number of Motor Poles
Sets the number of motor poles. Automatically set during Auto-Tuning. Default: 4
Min.: 2
Max.: 48
196
E2-05
(312)
Motor Line-to-Line
Resistance
Sets the phase-to-phase motor resistance. Automatically set during
Auto-Tuning.
Default:
<1>
Min.: 0.000 Ω
Max.: 65.000 Ω
196
E2-06
(313)
Motor Leakage Inductance
Sets the voltage drop due to motor leakage inductance as a percentage of motor
rated voltage. Automatically set during Auto-Tuning.
Default:
<1>
Min.: 0.0%
Max.: 40.0%
196
E2-10
(317)
Motor Iron Loss for Torque
Compensation
Sets the motor iron loss.
Default:
<1>
Min.: 0 W
Max.: 65535 W
196
E2-11
(318)
Motor Rated Power
Sets the motor rated power in kilowatts (1 HP = 0.746 kW). Automatically set
during Auto-Tuning.
Default:
<1>
Min.: 0.00 kW
Max.: 650.00 kW
196
<1> Default setting is dependent on parameter o2-04, Drive Model Selection.
<2> The number of decimal places in the parameter value depends on the drive model 1. This value has two decimal places (0.01 A) if the drive is set
for a maximum applicable motor capacity up to and including 11 kW, and one decimal place (0.1 A) if the maximum applicable motor capacity is
higher than 11 kW.
B.6 E: Motor Parameters
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
447
B
Parameter List
