<2> Unit is determined by S3-04.
n
S3-06: Secondary PI Proportional Gain Setting
Sets the proportional gain of the secondary PI controller. A setting of 0.00 disables P control.
No. Name Setting Range Default
S3-06 Secondary PI Proportional Gain Setting 0.00 to 25.00 1.00
n
S3-07: Secondary PI Integral Time Setting
Sets the integral time for the secondary PI controller. A setting of 0.0s disables integral control.
No. Name Setting Range Default
S3-07 Secondary PI Integral Time Setting 0.0 to 360.0 s 1.0 s
n
S3-08: Secondary PI Integral Limit Setting
Sets the maximum output possible from the integrator.
No. Name Setting Range Default
S3-08 Secondary PI Integral Limit Setting 0.0 to 100.0% 100.0%
n
S3-09: Secondary PI Output Upper Limit
Sets the maximum output possible from the secondary PI controller.
No. Name Setting Range Default
S3-09 Secondary PI Output Upper Limit 0 to 100.0% 100.0%
n
S3-10: Secondary PI Output Lower Limit
Sets the minimum output possible from the secondary PI controller.
No. Name Setting Range Default
S3-10 Secondary PI Output Lower Limit -100.00 to 100.00 0.00%
n
S3-11: Secondary PI Output Level Selection
Sets the secondary PI controller output direction.
No. Name Setting Range Default
S3-11 Secondary PI Output Level Selection 0 or 1 0
Setting 0: Normal Output (Direct Acting)
Setting 1: Reverse Output (Reverse Acting)
n
S3-12: Secondary PI Disable Mode
Selects the secondary PI controller output when disabled.
No. Name Setting Range Default
S3-12 Secondary PI Disable Mode 0 to 2 0
Setting 0: No Output (0%)
Setting 1: Lower Limit (S3-10)
Setting 2: Setpoint
n
S3-13: Secondary PI Low Feedback Detection Level
Sets the secondary PI low feedback detection level.
No. Name Setting Range Default
S3-13 Secondary PI Low Feedback Detection Level
0.00 to 600.00
<1>
0.00
<2>
<1> Upper limit is S3-02, decimal place holder is determined by S3-03.
<2> Unit is determined by S3-04.
5.11 S: Special Application
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
283
5
Parameter Details

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
