CIMR
-
P U 2 A
0021 F
A A
Drive
P1000
Series
No.
Enclosure
Type <1>
Design
Revision
Order
No.
Customized
Specifications
A Standard model
IP00/Open
Type
F
IP20/NEMA
Type 1
A
No.
Environmental
Specification <2>
K Gas-resistant
A
M
N
S
Standard
Humidity- and
dust-resistant
Oil-resistant
Vibration-resistant
Refer to the tables below
No.
Region
Code
USA
U
No. Voltage Class
3-phase, 380-480 Vac
3-phase, 200-240 Vac
2
4
3-phase, 500-600 Vac 5
<1> Refer to Drive Models and Enclosure Types on page 34 for differences regarding enclosure protection types and
component descriptions.
<2> Drives with these specifications do not guarantee complete protection for the environmental conditions indicated.
n
Three-Phase 200 V Class
Drive Model
Max. Motor Capacity kW (HP) Rated Output Current A
2A0004 0.75 (0.75) 3.5
2A0006 1.1 (1) 6.0
2A0008 1.5 (2) 8.0
2A0010 2.2 (3) 9.6
2A0012 3.0 (3) 12
2A0018 3.7 (5) 17.5
2A0021 5.5 (7.5) 21
2A0030 7.5 (10) 30
2A0040 11 (15) 40
2A0056 15 (20) 56
2A0069 18.5 (25) 69
2A0081 22 (30) 81
2A0110 30 (40) 110
2A0138 37 (50) 138
2A0169 45 (60) 169
2A0211 55 (75) 211
2A0250 75 (100) 250
2A0312 90 (125) 312
2A0360 110 (150) 360
2A0415 110 (175) 415
1.3 Model Number and Nameplate Check
32
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
