Drive Model Terminal
Recomm.
Gauge Without
Additional
Impedance
AWG, kcmil
Screw
Size
JST Ring Terminal
(non-insulated)
JST
Recomm.
Installation
Tool
JST
Crimphead /
Die Part No.
Insulation Cap
Model No.
5o0077
5o0099
R/L1, S/L2 4
M10
R22-10
YA-5
AD-953 TP-022
U/T1, V/T2, W/T3 8 R8-10 AD-951 TP-008
5o0125
R/L1, S/L2 1
M10
R38-10
YA-5
AD-954 TP-038
U/T1, V/T2, W/T3 6 R14-10 AD-952 TP-014
5o0145
R/L1, S/L2 1
M10
R38-10
YA-5
AD-954 TP-038
U/T1, V/T2, W/T3 6 R14-10 AD-952 TP-014
5o0192
R/L1, S/L2 3/0
M12
80-L12
YF-1
YET-300-1
TD-323,
TD-312
TP-080
U/T1, V/T2, W/T3 3 R38-12 YA-5 AD-954 TP-038
5o0242
R/L1, S/L2 3/0
M12
80-L12
YF-1
YET-300-1
TD-323,
TD-312
TP-080
U/T1, V/T2, W/T3 3 R38-12 YA-5 AD-954 TP-038
Table A.25 Panduit Closed-Loop Crimp Terminal Size Single-Phase With Additional Impedance
Drive Model Terminal
Recomm.
Gauge With
Additional
Impedance
AWG, kcmil
Screw
Size
Panduit Ring Terminal
(non-insulated)
Panduit
Recomm.
Installation
Tool
Panduit
Crimphead /
Die Part No.
Insulation Cap
Model No.
2o0004
2o0006
2o0008
2o0010
2o0012
R/L1, S/L2 14
M4 P14-8R CT-1570 - TP-003
U/T1, V/T2, W/T3 14
2o0018
2o0021
R/L1, S/L2 10
M4
P10-8R
CT-1570 -
TP-005
U/T1, V/T2, W/T3 14 P14-8R TP-003
2o0030
R/L1, S/L2 10
M4 P10-8R CT-1570 - TP-005
U/T1, V/T2, W/T3 12
2o0040
R/L1, S/L2 8
M4
P8-8R
CT-1701 -
TP-008
U/T1, V/T2, W/T3 12 P10-8R TP-005
2o0056
R/L1, S/L2 6
M6 P6-14R CT-1701 - TP-014
U/T1, V/T2, W/T3 6
2o0069
R/L1, S/L2 4
M8
P4-56R
CT-1701 -
TP-022
U/T1, V/T2, W/T3 10 P10-56R TP-005
2o0081
R/L1, S/L2 3
M8
P2-56R
CT-1701 -
TP-038
U/T1, V/T2, W/T3 8 P8-56R TP-008
2o0110
R/L1, S/L2 4
M8
P4-56R
CT-1701 -
TP-022
U/T1, V/T2, W/T3 10 P10-56R TP-005
2o0138
R/L1, S/L2 2
M10
P2-38R
CT-1701 -
TP-038
U/T1, V/T2, W/T3 8 P8-38R TP-008
2o0169
R/L1, S/L2 1/0
M10
S1/0-38R-X
CT-720
CD-720-2 TP-060
U/T1, V/T2, W/T3 6 S6-38R-E CD-720-1 TP-014
2o0211
R/L1, S/L2 2/0
M10
S2/0-38R
CT-720 CD-720-2
TP-060
U/T1, V/T2, W/T3 1/0 S1/0-38R TP-038
2o0250
R/L1, S/L2 4/0
M12
S4/0-12R-5
CT-720
CD-720-2 TP-100
U/T1, V/T2, W/T3 3 S2-12R-X CD720-3 TP-038
2o0312
R/L1, S/L2 1/0 X 2P
M12
S1/0-12R-X (Qty. 2)
CT-720 CD-720-2
TP-038 (Qty. 2)
U/T1, V/T2, W/T3 1 S2-12R-X TP-060
2o0360
R/L1, S/L2 2/0 X 2P
M12
S2/0-12R-X (Qty. 2)
CT-720 CD-720-2
TP-080 (Qty. 2)
U/T1, V/T2, W/T3 2/0 S2/0-12R-X TP-080
