Three-Phase 400 V Class
Drive Model
Rated Current [A]
Normal Duty Rating (ND)
2 kHz 8 kHz 15 kHz
4A0038 38 31 18.6
4A0044 44 39 23.4
4A0058 58 45 27
4A0072 72 60 36
4A0088 88 75 45
4A0103 103 91 55
Three-Phase 400 V Class
Drive Model
Rated Current [A]
Normal Duty Rating (ND)
2 kHz 5 kHz 10 kHz
4A0139 139 112 78
4A0165 165 150 105
4A0208 208 180 126
4A0250 250 216 151
4A0296 296 260 182
4A0362 362 304 213
4A0414 414 370
4A0515 515 397
4A0675 675 528
4A0930 930 716
4A1200 1200 938
Table A.33 Carrier Frequency and Current Derating
Three-Phase 600 V Class
Drive Model
Rated Current [A]
Normal Duty Rating (ND)
2 kHz 8 kHz 10 kHz 15 kHz
5A0003 2.7 2.2 2.0 1.3
5A0004 3.9 3.4 3.1 2.1
5A0006 6.1 4.9 4.3 2.9
5A0009 9 7.5 6.6 4.5
5A0011 11 9.3 8.2 5.6
5A0017 17 13.3 11.8
5A0022 22 17.0 15.1
5A0027 27 22.0 19.5
5A0032 32 27.3 24.4
Three-Phase 600 V Class
Drive Model
Rated Current [A]
Normal Duty Rating (ND)
2 kHz 5 kHz 8 kHz 10 kHz
5A0041 41.0 39.7 33.5 29.4
5A0052 52.0 50.3 42.5 37.3
5A0062 62.0 61.3 49.7 41.9
5A0077 77.0 76.2 61.7 52.0
5A0099 99.0 80.0 55.1
A.4 Drive Derating Data
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
427
