YASKAWA P1000

Drive Model
Wire Gauge (AWG, kcmil)
Screw
Size
Crimp
Terminal
Model
Number
Tool
Insulation
Cap Model
No.
Code
<1>
R/L1, S/L2, T/L3 U/T1, V/T2, W/T3 Machine No. Die Jaw
2A0415
250 × 2P –
M12
150-L12
YF-1
YET-300-1
TD-325,
TD-313
TP-150 100-051-562
300 × 2P 300 × 2P
350 × 2P 350 × 2P 180-L12
TD-327,
TD-314
TP-200
100-066-688
400 × 2P 200-L12 100-051-564
500 × 2P
325-12
TD-328,
TD-315
TP-325 100-051-277
600 × 2P
400 V Class
4A0002
4A0004
4A0005
4A0007
4A0009
14
M4
R2-4
YA-4 AD-900
TP-003 100-054-028
12
R5.5-4 TP-005 100-054-029
10
4A0011
14 14
M4
R2-4
YA-4 AD-900
TP-003 100-054-028
12 12
R5.5-4 TP-005 100-054-029
10
4A0018
12
M4
R5.5-4
YA-4
AD-900 TP-005 100-054-029
10
8 8-4 AD-901 TP-008 100-054-031
6 14-NK4 AD-902 TP-014 100-054-033
4A0023
10
M4
R5.5-4
YA-4
AD-900 TP-005 100-054-029
8 8-4 AD-901 TP-008 100-054-031
6 14-NK4 AD-902 TP-014 100-054-033
4A0031
– 10
M5
R5.5-5
YA-4
AD-900 TP-005 100-054-030
8 R8-5 AD-901 TP-008 100-054-032
6 R14-5 AD-902 TP-014 100-054-034
4A0038
8 8
M5
R8-5
YA-4
AD-901 TP-008 100-054-032
6 6 R14-5 AD-902 TP-014 100-054-034
4A0044
6
M6
R14-6
YA-5
AD-952 TP-014 100-051-261
4 R22-6 AD-953 TP-022 100-051-262
4A0058
6
M8
R14-8
YA-5
AD-952 TP-014 100-054-035
4 R22-8 AD-953 TP-022 100-051-263
4A0072
4
M8
R22-8
YA-5
AD-953 TP-022 100-051-263
3 R38-8 AD-954 TP-038 100-051-264
4A0088
3
M8
R38-8
YA-5
AD-954 TP-038 100-051-2642
1
1/0 R60-8 AD-955 TP-060 100-051-265
4A0103
2
M8
R38-8
YA-5
AD-954 TP-038 100-051-264
1 1
1/0 1/0 R60-8 AD-955 TP-060 100-051-265
4A0139
1/0
M10
R60-10
YF-1
YET-300-1
TD-321,
TD-311
TP-060 100-051-266
2/0 2/0 70-10
TD-323,
TD-312
TP-080
100-054-036
3/0 3/0 80-10 100-051-267
4/0 R100-10
TD-324,
TD-312
TP-100 100-051-269
4A0165
3/0
M10
80-10
YF-1
YET-300-1
TD-323,
TD-312
TP-080 100-051-267
4/0 R100-10
TD-324,
TD-312
TP-100 100-051-269
