YASKAWA P1000

Drive Model
Nominal
Output Power
HP
AC Drive Input
Amps
MCCB Rating
Amps
<1>
Time Delay Fuse
Rating Amps
<2>
Non-time Delay
Fuse Rating
Amps
<3>
Bussman Semi-
conductor Fuse
Rating (Fuse
Ampere)
<4>
400 V Class
4A0002 1 2.1 15 3.5 6 FWH-40B (40)
4A0004 2 4.3 15 7.5 12 FWH-50B (50)
4A0005 3 5.9 15 10 17.5 FWH-70B (70)
4A0007 3 8.1 15 12 20 FWH-70B (70)
4A0009 5 9.4 15 15 25 FWH-90B (90)
4A0011 7.5 14 25 20 40 FWH-90B (90)
4A0018 10 20 40 35 60 FWH-80B (80)
4A0023 15 24 45 40 70 FWH-100B (100)
4A0031 20 38 75 60 110 FWH-125B (125)
4A0038 25 44 75 75 125 FWH-200B (200)
4A0044 30 52 100 90 150 FWH-250A (250)
4A0058 40 58 100 100 150 FWH-250A (250)
4A0072 50 71 125 110 200 FWH-250A (250)
4A0088 60 86 150 150 250 FWH-250A (250)
4A0103 75 105 200 175 300 FWH-250A (250)
4A0139 100 142 250 225 400 FWH-350A (350)
4A0165 125 170 300 250 500 FWH-400A (400)
4A0208 150 207 400 350 600 FWH-500A (500)
4A0250 200 248 450 400 700 FWH-600A (600)
4A0296 250 300 600 500 800 FWH-700A (700)
4A0362 300 346 600 600
1000
<5>
FWH-800A (800)
4A0414 350 410 800 700
1200
<5>
FWH-800A (800)
4A0515 400 - 450 465 900 800
1350
<5>
FWH-1000A (1000)
4A0675 500 - 600 657 1200
1100
<5>
1800
<5>
FWH-1200A (1200)
4A0930 700 - 800 922
Not Applicable
FWH-1200A (1200)
4A1200 900 - 1000 1158 FWH-1600A (1600)
600 V Class
5A0003 2 3.6 15 6.25 10 FWP-50B (50)
5A0004 3 5.1 15 8 15 FWP-50B (50)
5A0006 5 8.3 15 12 20 FWP-60B (60)
5A0009 7.5 12 20 20 35 FWP-60B (60)
5A0011 10 16 30 25 45 FWP-70B (70)
5A0017 15 23 40 40 60 FWP-100B (100)
5A0022 20 31 60 50 90 FWP-100B (100)
5A0027 25 38 75 60 110 FWP-125A (125)
5A0032 30 45 75 75 125 FWP-125A (125)
5A0041 40 44 75 75 125 FWP-175A (175)
5A0052 50 54 100 90 150 FWP-175A (175)
5A0062 60 66 125 110 175 FWP-250A (250)
5A0077 75 80 150 125 225 FWP-250A (250)
5A0099 100 108 175 175 300 FWP-250A (250)
5A0125 125 129 225 225 350 FWP-350A (350)
5A0145 150 158 300 275 450 FWP-350A (350)
5A0192 200 228 400 350 600 FWP-600A (600)
5A0242 250 263 500 450 700 FWP-600A (600)
<1> Maximum MCCB Rating is 15 A, or 200 % of drive input current rating, whichever is larger. MCCB voltage rating must be 600 VAC or greater.
<2> Maximum Time Delay fuse is 175% of drive input current rating. This covers any Class CC, J or T class fuse.
D.3 UL and CSA Standards
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
563
