No. Name
User
Setting
L3-23
Automatic Reduction Selection for Stall Prevention
during Run
L3-24 Motor Acceleration Time for Inertia Calculations
L3-25 Load Inertia Ratio
L3-26 Additional DC Bus Capacitors
L3-27 Stall Prevention Detection Time
L4-01 Speed Agreement Detection Level
L4-02 Speed Agreement Detection Width
L4-03 Speed Agreement Detection Level (+/-)
L4-04 Speed Agreement Detection Width (+/-)
L4-05 Frequency Reference Loss Detection Selection
L4-06 Frequency Reference at Reference Loss
L4-07 Speed Agreement Detection Selection
L5-01 Number of Auto Restart Attempts
L5-02 Auto Restart Fault Output Operation Selection
L5-04 Fault Reset Interval Time
L5-05 Fault Reset Operation Selection
L6-01 Torque Detection Selection 1
L6-02 Torque Detection Level 1
L6-03 Torque Detection Time 1
L6-04 Torque Detection Selection 2
L6-05 Torque Detection Level 2
L6-06 Torque Detection Time 2
L6-13 Motor Underload Protection Selection
L6-14
Motor Underload Protection Level at Minimum
Frequency
L8-01
Internal Dynamic Braking Resistor Protection
Selection (ERF type)
L8-02 Overheat Alarm Level
L8-03 Overheat Pre-Alarm Operation Selection
L8-05 Input Phase Loss Protection Selection
L8-07 Output Phase Loss Protection
L8-09 Output Ground Fault Detection Selection
L8-10 Heatsink Cooling Fan Operation Selection
L8-11 Heatsink Cooling Fan Off Delay Time
L8-12 Ambient Temperature Setting
L8-15 oL2 Characteristics Selection at Low Speeds
L8-18 Software Current Limit Selection
L8-19
Frequency Reduction Rate during Overheat
Pre-Alarm
L8-32
Main Contactor and Cooling Fan Power Supply
Failure Selection
L8-35 Installation Method Selection
L8-38 Carrier Frequency Reduction Selection
L8-40 Carrier Frequency Reduction Off-Delay Time
L8-41 High Current Alarm Selection
L8-55 Internal Braking Transistor Protection
L8-78 Power Unit Output Phase Loss Protection
L8-93 LSo Detection Time at Low Speed
L8-94 LSo Detection Level at Low Speed
L8-95 Average LSo Frequency at Low Speed
No. Name
User
Setting
n1-01 Hunting Prevention Selection
n1-02 Hunting Prevention Gain Setting
n1-03 Hunting Prevention Time Constant
n1-05 Hunting Prevention Gain while in Reverse
n3-01 High-Slip Braking Deceleration Frequency Width
n3-02 High-Slip Braking Current Limit
n3-03 High-Slip Braking Dwell Time at Stop
n3-04 High-Slip Braking Overload Time
n3-13 Overexcitation Deceleration Gain
n3-14
High Frequency Injection during Overexcitation
Deceleration
n3-21 High-Slip Suppression Current Level
n3-23 Overexcitation Operation Selection
o1-01
Drive Mode Unit Monitor Selection
o1-02
User Monitor Selection After Power Up
o1-03 Digital Operator Display Selection
o1-06 User Monitor Selection Mode
o1-07 Second Line Monitor Selection
o1-08 Third Line Monitor Selection
o1-09 Frequency Reference Display Units
o1-10 User-Set Display Units Maximum Value
o1-11 User-Set Display Units Decimal Display
o1-13
Frequency Reference and Frequency Related
Monitor Custom Units 1
o1-14
Frequency Reference and Frequency Related
Monitor Custom Units 2
o1-15
Frequency Reference and Frequency Related
Monitor Custom Units 3
o2-01 LO/RE Key Function Selection
o2-02 STOP Key Function Selection
o2-03 User Parameter Default Value
o2-04 Drive Model Selection
o2-05 Frequency Reference Setting Method Selection
o2-06
Operation Selection when Digital Operator is
Disconnected
o2-07 Motor Direction at Power Up when Using Operator
o2-20
Operator RUN Save at Power Loss
o3-01 Copy Function Selection
o3-02 Copy Allowed Selection
o4-01 Cumulative Operation Time Setting
o4-02 Cumulative Operation Time Selection
o4-03 Cooling Fan Maintenance Operation Time Setting
o4-05 Capacitor Maintenance Setting
o4-07 DC Bus Pre-charge Relay Maintenance Setting
o4-09 IGBT Maintenance Setting
o4-11 U2, U3 Initialize Selection
o4-12 kWh Monitor Initialization
o4-13 Number of Run Commands Counter Initialization
