YASKAWA P1000

n
IP00/Open Type Enclosure Drives
Figure 1
W1
4-d
H1
H
H2
Max W2
W
t2
t1
D1
D
D1
D
t2
H1
H2
H
4-d
W1
W
Max W2
t1
Figure 2
D1
D
W
H1
H2
H
6-d
t2
Figure 3
t1
W1
W3
W3
Max W2
Max W2
Max W2
Max W2
Figure 4
W3 W3
8-d
W4
W1
H1
W
H2
D
H
D1
t2
t1
Max W2Max W2
Table 2.9 Dimensions for IP00/Open Type Enclosure: 200 V Class
Drive
Model
Figure
Dimensions mm (in)
Wt. kg
(lb)
W H D W1 W2 H1 H2 D1 t1 t2 d
2A0250A
<1>
1
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
680
(26.77)
12
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
76
(167.6)
2A0312A
<1>
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
680
(26.77)
12
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
80
(176.4)
2A0360A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
98
(216.1)
2A0415A
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
99
(218.3)
<1> Customers may convert these models to IP20/NEMA 1, UL Type 1 enclosures using an IP20/NEMA 1, UL Type 1 Kit.
2.2 Mechanical Installation
62
