A - 2 TC75 User Guide
Performance Characteristics
CPU 1.7 GHz dual-core.
Operating System Android-based AOSP and GMS V5.1.1
Memory 1 GB RAM/8 GB Flash
User Environment
Operating Temperature -20 °C to 50 °C (-4 °F to 122 °F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0° C to 40° C (32°F to 104°F)
Humidity 5 to 85% non-condensing
Drop Specification 8 ft./2.4 m to concrete at room temperature; 6 ft./1.8 m over the operating
temperature range
Tumble 2,000 3.2 ft./1.0 m tumbles; meets and exceeds IEC tumble specifications
Electrostatic Discharge (ESD) +/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect discharge
Sealing IP67 per applicable IEC sealing specifications
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to 2 kHz); 60 minute
duration per axis, 3 axis
Thermal Shock -40° C to 70° C (-40° F to 158° F) rapid transition
Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer provides motion-sensing for dynamic screen orientation
and power management
Light Sensor Ambient light sensor to auto adjust display backlight brightness
Wireless WAN Data and Voice Communications
Wireless Wide Area Network
(WWAN) radio
TBS
Frequency band
Worldwide:
LTE: 800/850/900/1800/2100/2600 (FDD 20,5,8,3,1,7)
UMTS/HSPA/HSPA+: 850/900/1900/2100
GSM/GPRS/EDGE: 850/900/1800/1900
Americas:
LTE: 700/850/1900/AWS/2100 (FDD 17,5,2,4,1)
UMTS/HSPA/HSPA+: 850, 900, AWS, 1900, 2100
GSM/GPRS/EDGE: 850/900/1800/1900
GPS Integrated, Autonomous, Assisted GPS (A-GPS), Navstar, GLONASS
Table A-1 TC75 Technical Specifications (Continued)
Item Description
