Technical Specifications A - 3
Wireless LAN Data and Voice Communications
Radio
IEEE
®
802.11a/b/g/n/d/h/i/k/r
Data Rates Supported 5GHz: 802.11a/n - up to 150 Mbps
2.4GHz: 802.11b/g/n - up to 72.2 Mbps
Operating Channels 5 GHz: Chan 36 - 165 (5180 - 5825 MHz)
2.4 GHz: Chan 1 - 11 (2412 – 2462 MHz) – North America (FCC and IC)
Chan 1 - 13 (2412 - 2472 MHz) – Rest of the World
Actual operating channels/frequencies depend on regulatory rules and
certification agency
Security
Security Modes:
Legacy, WPA and WPA2
Encryption:
WEP (40 and 104 bit), TKIP and AES
Authentication:
TLS, TTLS (MS-CHAP), TTLS (MS-CHAP v2), TTLS (PAP),
PEAP (MS-CHAP v2), PEAP (GTC), FAST (MS-CHAP v2), FAST (GTC), LEAP.
Fast Roam:
PMKID, OKC, CCKM
Voice Communications Voice-over-IP ready, Wi-Fi™-certified, IEEE 802.11a/b/g/n direct sequence
wireless LAN, Wi-Fi Multimedia™ (WMM)
Wireless PAN Data and Voice Communications
Bluetooth Bluetooth v4.0 Low Energy
Data Capture Specifications
2D Imager SE4750-SR – 1D and 2D bar codes.
Near Field Communications
(NFC)
ISO 14443 Type A & B, FeliCa, and ISO 15963 cards. Secure NFC via SAM
supporting Mifare, Calypso and FeliCa. P2P mode and Card Emulation via
UICC and Host.
Communication and Messaging
Workforce Connect PTT Express (included) for instant PTT calls between workers inside the four walls; Workforce
Connect PTT Pro (supported) for PTT calls and text messaging over Wi-Fi and cellular networks; Workforce
Connect Voice client (supported) to enable PBX handset functionality and more inside the four walls.
2D Imager Engine (SE4750-SR) Specifications
Field of View Horizontal - 48.0°
Vertical - 36.7°
Image Resolution 1280 horizontal X 960 vertical pixels
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 10,000 ft. candles (107,639 lux)
Table A-1 TC75 Technical Specifications (Continued)
Item Description
