1-5
Table 1-5 Configuration task list for a port in manual voice VLAN assignment mode
Task Remarks
Configuring Voice VLAN Globally
Optional
Configure the voice VLAN to operate in security mode
and configure the aging timer.
Assigning the port to the voice VLAN
Required
Note that after an access port is assigned to the voice
VLAN, the voice VLAN automatically becomes the
default VLAN of the access port.
For details, refer to VLAN Configuration.
Configuring the Voice VLAN as the
Default VLAN of a Hybrid or Trunk Port
Optional
This task is required if the incoming voice traffic is
untagged and the link type of the receiving port is trunk
or hybrid. If the incoming voice traffic is tagged, do not
perform this task.
For details, refer to Port Management Configuration.
Configuring Voice VLAN on a Port
Required
Configure the voice VLAN assignment mode of a port as
manual and enable voice VLAN on the port.
By default, the voice VLAN assignment mode of a port is
automatic, and voice VLAN is disabled on a port.
Adding OUI Addresses to the OUI List
Optional
You can configure up to 16 OUI addresses.
By default, the system is configured with the seven OUI
addresses shown in
Table 1-1.
Configuring Voice VLAN Globally
Select Network > Voice VLAN from the navigation tree, and click the Setup tab on the displayed page
to enter the page shown in
Figure 1-1.
Figure 1-1 Configure voice VLAN
Table 1-6 describes the global voice VLAN configuration items.
Table 1-6 Global voice VLAN configuration items
Item Description
Voice VLAN security
Select Enable or Disable in the drop-down list to enable or
disable the voice VLAN security mode.
By default, the voice VLANs operate in security mode.
