1-8
Figure 1-3 The Setup tab
After finishing each configuration item, click the right Apply button to submit the configuration.
Table 1-6 describes the configuration items.
Table 1-6 LACP priority configuration items
Item Description
Select LACP enabled port(s) parameters Set a port LACP priority.
Select port(s) to apply Port Priority
Select the ports where the port LACP priority you set
will apply on the chassis front panel.
(You can set LACP priority not only on LACP-enabled
ports but also on LACP-disabled ports.)
System Priority Set the LACP priority of the local system
Return to
Dynamic aggregation group configuration task list.
Displaying Information of LACP-Enabled Ports
Select Network > LACP from the navigation tree. The Summary tab is displayed by default, as shown
in
Figure 1-4.
