Figure 1-4 Display the information of LACP-enabled ports
The upper part of the page displays a list of all LACP-enabled ports on the device and information about
them. To view information about the partner port of a LACP-enabled port, select it in the port list, and
then click View Details. Detailed information about the peer port will be displayed on the lower part of
the page.
Table 1-7 describes the fields on the Summary tab.
Table 1-7 Fields in the LACP-enabled port summary table
Field/button Description
Unit The ID of a device in a stack
Port Port where LACP is enabled
LACP State State of LACP on the port
Port Priority LACP priority of the port
State
Active state of the port. If a port is selected, its state is active and the ID of
the aggregation group it belongs to will be displayed.
