Expansion Stages and System Capacity
56
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
Reserving audio channels
The allocation of audio channels between voice mail, Auto Attendant and call re-
cording is set under Reservation audio channels in the AMS Configuration Manager.
An audio channel for Auto Attendant is always used in cases where an incoming
call results in greetings being played back from mailboxes which have been as-
signed an Auto Attendant profile. In all other cases one audio channel is used for
voice mail in connection with the voice mail system. Audio channels for call record-
ing are used exclusively for the manual or automatic recording of phone calls.
Tab. 18 Reserving audio channels
No voice channels are reserved after a first start and they can be used for voice
mail, Auto Attendant or call recording.
Configuration of DSP chips
The assignable functions for each DSP chip are specified in the AMS Configuration
Manager in the DSP configuration. The DSP modules provide additional functions
as indicated in the following table. All the possible combinations are listed, with the
maximum number of voice channels.
Tab. 19 Max. number of voice channels per DSP chip on CPU1, SM-DSPX1 or SM-DSPX2
Parameter Explanation
Available audio channels Maximum available audio channels on this node. This
value depends on the DSP configuration under CM_2.1.3.
Reserved for voice mail Number of audio channels on this node that can be used
exclusively for voice mail.
Reserved for Auto Attendant: Number of audio channels on this node that can be used
exclusively for Auto Attendant.
Reserved for call recording Number of audio channels on this node that can be used
exclusively for call recording.
Not reserved/sharable Number of audio channels on this node that can be used
for voice mail, Auto Attendant or call recording, depend-
ing on where they happen to be required.
DECT VoIP
1)
FoIP Audio
1)
GSM
1)
FXO CAS
2)
Remarks
10
812
85
4325
42410
41220
4 12 150
