6253 DC Voltage Current Source/Monitor Operation Manual
4.2.15 Self-Test
4-76
(*1) TER? command response register and data
In the error register (ERR?) the following bits are set.
• At power ON: bit 0
• In executing the self-test: bit1
2. Self-test execution by manual operation
When executing the self test by manual operation, select the parameters 13) System and 4) Self Test
in that order in the menu.
232 Low Limit 30 V +FS 
e
1
233 Low Limit 30 V -FS  2
234 Low Limit 100 V +FS  4
235 Low Limit 100 V -FS  8
236 IM 3 A ZERO  16
237 IM 30 A ZERO  32
238 IM 300 A ZERO  64
239 IM 3 mA ZERO  128
240 IM 30 mA ZERO  256
241 IM 300 mA ZERO  512
242 IM 2 A ZERO  1024
301 OVL detection check  4096
Self-test item Description
1) Self Test Press the ENTER key to execute the self-test.
Press the EXIT key to finish.
2) LCD Pattern Display Press the ENTER key to execute the display test.
Press the EXIT key to finish.
3) Key & Buzzer Test Press the ENTER key to execute the key and buzzer test.
Press the EXIT key to finish.
Table 4-18 Self-Test Items (3 of 3)
Error code Description
Execution method TER register (*1)
Power ON *TST? Register Data
