6253 DC Voltage Current Source/Monitor Operation Manual
3.2.7 TRIG Key and SWP STOP Key (Trigger/Sweep Stop)
3-16
3.2.7 TRIG Key and SWP STOP Key (Trigger/Sweep Stop)
TRIG key: Functions as source or measurement trigger key.
SWP STOP key (shift mode): Stops sweep.
3.2.8 HOLD Key (Trigger Mode)
The HOLD key is used to switch the trigger mode for source and measurement.
Source mode AUTO HOLD
DC/Pulse -
Triggers measurement and
pulse source.
Sweep
Before sweep
start
Starts sweep. Starts sweep.
During sweep - Moves to the next step.
Source mode AUTO HOLD
DC/Pulse - -
Sweep
Before sweep
start
--
During sweep Stops sweep. Stops sweep.
Source mode AUTO HOLD
DC/Pulse
Repeats source and measurement with
the period time of the time parameter.
Executes source and measurement by
trigger input.
The HOLD key is lit.
Sweep
Executes source and measurement by
one step by trigger input, and pauses
sweep.
The HOLD key is lit.
*Invalid in the Burst mode.
