1.4.2 Power Specification
1-7
1.4.2 Power Specification
Table 1-3 below shows the 6253 power supply specifications.
Ensure that the power voltage setting on the 6253 rear panel matches the voltage of the commercial power
supply.
Figure 1-3 Setting Power Voltage Indicator
Table 1-3 Power Supply Specification
Standard
Optional
32 42 44
100 VAC 120 VAC 220 VAC 240 VAC
Input voltage range 90 V to 110 V 108 V to 132 V 198 V to 242 V 216 V to 250 V
Frequency range 48 Hz to 66 Hz
Power consumption 330 VA or less
Fuse F5 A/250 V F4 A/250 V
Setting voltage indicator
