1) Mode Source mode
DC/Pulse/DC Sweep/Pulse Sweep
2) Pulse Base Base value at pulse source
VS IS
-110.000 V to +110.000 V +0.00000 A to 2.00000 A
3) Suspend V Output voltage in the Suspend status
-110.000 V to +110.000 V
4) Suspend Z Output impedance in the Suspend status
HiZ/LoZ
5) Limit Input Limit setting
±Balance/Individual
6) Response Output response
Fast/Slow
7) Slew Rate SW Slew rate setting
ON/OFF
8) Slew Rise Slew rate rise time setting
+10.00 V/s to +99.99 kV/s
9) Slew Fall Slew rate fall time setting
+10.00 V/s to +99.99 kV/s
10) Slew Rate Indiv Slew rage rise and fall time individual setting
ON/OFF
MENU
1) Source
Category Edit (Input/Run level)Select
1) Sweep Type Sweep source mode
Linear/Fixed/Random/MLinear/Log
2) Sweep Range Sweep source range
Auto/Fix *Fix only for the Burst mode
3) Sweep Reverse Sweep reverse mode
Single/Reverse
4) Repeat Count Sweep repeat count
0 to 1000 *Invalid in the Burst mode.
5) Return Bias Bias value output at the end of sweep
ON/OFF
2) Sweep Mode
